Specifications |
|
| Model | FH |
| Laser Power | 20W-100W |
| Laser Wavelength | 1064nm |
| Q-frequency | 20KHZ-100KHZ |
| PMW | 0-20 Adjustable |
| Divergence | 0.3mard |
| Marking Range | 110*110mm/150*150mm/175*175mm/200*200mm/300*300mm(optional) |
| Minimum Character | 0.5mm |
| Minimum Line Width | 0.01mm |
| Minimum Depth | 0-1mm(Depending on the materials) |
| Engraving Line Speed | ≤7000mm/s |
| Scope of Marking | All metals and some non-metals (such as hard plastics) |
| Consumables | No consumables |
| Marking thickness | depends on different materials and is related to the hardness of the materials |
| Laser head and service life | Theoretical lifespan 100000 hours |
| Warranty period | One year warranty for the entire machine, two years warranty for the laser |
| Working Size | default 110 * 100mm, can be selected according to needs |
| Repeatability Accuracy | ±0.001mm |
| Beam Quality | M2:1.2-1.8 |
| Marking Format | Graphics,text,bar codes,two-dimension code,automatically marking the date, batch number,serial number, frequency,etc |
| Graphic Format Supported | BMP,JPG,GIF,PNG,TIF,AI,DXF,DST,PLT,etc. |
| Working Voltage | 220V/50HZ/4A |
| Unit Power | <0.5kw |
| Working Environment Required | Clean and dust free or dust less |
| Working Condition | humidity 5%-95%,Free of condensed water |
| Laser Module Life | Around 100000 hours |
| Laser Source | MAX/RAYCUS/JPT |
| Control Card | JCZ Brand EZCAD |
Product Description:
Handheld fiber laser marking machines are highly efficient and energy-saving in practical applications, with meager operating costs due to the absence of consumables. Additionally, the marking process does not produce any polluting gases, thus having no negative impact on the environment. As handheld laser marking machines become more widespread and market demand increases, their prices become more affordable, making them accessible to a broader range of businesses.
Currently, handheld laser marking machines have found extensive applications in industries such as mechanical manufacturing, packaging, and consumer DIY. They help businesses achieve higher production efficiency while ensuring product quality. With further power increases, handheld fiber laser marking machines are expected to gain broader applications in emerging markets, such as handheld engraving and marking.
Application of mini fiber laser marking machine
Suitable for all kinds of metal materials and some non-metal materials marking, engraving. Large machinery parts, automobile and mechanical parts, hardware tools, instruments and meters, aerospace and aviation components; Electronic and communication products, integrated circuit chips, computer accessories and electrical appliances;
Jewelry, clocks and watches, gifts, office supplies, trademarks, sanitary ware; Tableware, food, beverage, tobacco and alcohol and other areas of graphic and text marking, as well as mass production line operations.
